4000w solar inverter
BSSI-V Series (2.2KW/3.2KW/4.2KW/6.2KW/7KW/10.2KW)Key Features
●Pure sine wave solar inverter(on/off Grid)
●Programmable supply priority for PV, battery or Grid
●High PV input voltage range(55~450VDC)
●Built-in Max 110A (2.2KW&3.2KW 80A, 4.2KW&6.2KW 110A)MPPT solar charge
●Compatible with lithium-ion battery
●Support BMS communication with Lithium battery
●Smart battery charge design to optimize battery life
●Cold start function
●Intelligent fan speed adjustment
●Built-in anti-dusk kit for harsh environment(2200VA/3200VA/4200VA/6200VA)
●WIFI available for IOS and Android (optional)
Description
This 4000w solar inverter is an intelligent high-frequency inverter control integrated machine with an excellent conversion efficiency of 98%. It can adapt to the maximum open circuit voltage of the photovoltaic array up to 450VDC, the output voltage is 230vac and 12v voltage, and has a power of 80amppt. At the same time, it also uses RS485 as a standard communication interface, which is convenient for users to use and control. This inverter is not only efficient, but also intelligent, and can be optimized and adjusted according to the provided Context information to achieve better performance. Whether in home or commercial use, this inverter can bring users a long-lasting clean energy experience.
Specification
MODEL | BSSI-V-G2200 | BSSI-V-G4200 |
Rated Power | 2200V / 1800W | 4200V / 3800W |
INPUT | ||
Voltage | 230VAC | |
Selectable Voltage Range | 170-280VAC（for personal computers) | |
Frequency Range | 50Hz/60Hz(Auto aensing) | |
OUTPUT | ||
AC Voltage Regulation (Batt.Mode) | 230VAC±5% | |
Surge power | 4400VA | 8000VA |
Transfer Time | 10ms(for personal computers) | |
Wave form | Pure Sine Wave | |
BATTERY & AC CHARGER | ||
Battery Voltage | 12VDC | 24VDC |
Floating Charge Voltage | 13.5VDC | 27VDC |
Overcharge Protection | 15.5VDC | 31VDC |
Maximum Charge current | 60A | 80A |
SOLAR CHARGER | ||
MAX.PV Array Power | 2000W | 6000W |
MPPT Range @Operating Voltage | 55-450VDC | |
Maximum PV Array Open Circuit Voltage | 450VDC | |
Maximum Charging current | 80A | 110A |
Maximum Efficiency | 98% | |
PHYSICAL | ||
Dimension. D*W*H(mm) | 405×286×98MM | 423×290×100MM |
Net Weight (kgs) | 4.5Kg | 7Kg |
Communication Interface | RS232/RS485（Standard） | |
OPERATING ENVIRONMENT | ||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
Operating Temperature | -10°C to 55°C | |
Storage Temperature | -15°C to 60°C | |
