6kw on off grid solar inverter
BSSI-V Series (2.2KW/3.2KW/4.2KW/6.2KW/7KW/10.2KW)Key Features
●Pure sine wave solar inverter(on/off Grid)
●Programmable supply priority for PV, battery or Grid
●High PV input voltage range(55~450VDC)
●Built-in Max 80A (3KW & 6.2KW)MPPT solar charge
●Compatible with lithium-ion battery
●Support BMS communication with Lithium battery
●Smart battery charge design to optimize battery life
●Overload, high temperature, inverter output short circuit protection
●Cold start function
●Intelligent fan speed adjustment
●Built-in anti-dusk kit for harsh environment(3200VA/6200VA)
●WIFI available for IOS and Android (optional)
Description
6kw on off grid inverter is a powerful intelligent solar inverter control integrated machine. It adopts pure sine wave output, which can efficiently convert DC power into AC power, ensuring the stability and reliability of power supply. This hybrid inverter has a high photovoltaic input voltage range, which can meet the needs of different photovoltaic cell groups and ensure maximum power generation efficiency. The inverter also has an intelligent charging setting function, which can automatically perform reasonable charging control according to the state of the battery to prolong the service life of the battery. It also supports OEM/ODM customization, which can be personalized designed and manufactured according to customer needs. Most importantly, the conversion efficiency of the Busbyr 6000w off-grid inverter is as high as 96%, which can effectively utilize solar energy resources and provide users with reliable power supply.
Specification
MODEL | BSSI-V-B3200 | BSSI-V-B7000 |
Rated Power | 3200VA/3000W | 7000VA/6200W |
INPUT | ||
Voltage | 230VAC | |
Selectable Voltage Range | 170-280VAC（for personal computers) | |
Frequency Range | 50Hz/60Hz(Auto aensing) | |
OUTPUT | ||
AC Voltage Regulation (Batt.Mode) | 230VAC±5% | |
Surge power | 6400VA | 14000VA |
Transfer Time | 10ms(for personal computers) | |
Wave form | Pure Sine Wave | |
BATTERY & AC CHARGER | ||
Battery Voltage | 24VDC | 48VDC |
Floating Charge Voltage | 27VDC | 54VDC |
Overcharge Protection | 31VDC | 61VDC |
Maximum Charge current | 80A | 80A |
SOLAR CHARGER | ||
MAX .PV Array Power | 3000W | 6000W |
MPPT Range @Operating Voltage | 55-450VDC | |
Maximum PV Array Open Circuit Voltage | 450VDC | |
Maximum Charging current | 80A | 110A |
Maximum Efficiency | 98% | |
PHYSICAL | ||
Dimension. D*W*H(mm) | 405×286×98MM | 423×310×106MM |
Net Weight (kgs) | 5Kg | 8.0Kg |
Communication Interface | RS232/RS485（Standard） | |
OPERATING ENVIRONMENT | ||
Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
Operating Temperature | -10°C to 55°C | |
Storage Temperature | -15°C to 60°C | |
