8.2kw solar power inverter for home
BS4 Max Series (7.2/8.2/10.2KW)Key Features
●Pure sine wave solar inverter(on/off Grid)
●PF=1.0
●Smart WIFI and GPRS system allows to monitor PV system
●Inverter running without battery
●One-key restoration to factory Settings
●Built-in Lithium battery automatic activation
●Built-in 160A MPPT solar charger
●High PV input voltage range(90~500VDC)
●Smart battery charge design to optimize battery life
●Dual output
●Touch button
Description
8.2kw solar power inverter have a touch button and dual output and built-in 160A MPPT solar charger function. Smart WIFI and GPRS system allow monitoring of PV systems. The Busbyr inverters have a 10 years product warranty. Max series is the latest 1-phase inverter solution designed specifically for home use. The BS4-Max series features an aesthetically pleasing, compact design that will add visual appeal to your home. With an outstanding efficiency of up to 98%, this is a smart choice that offers great performance at an excellent price point.
Specification
MODEL | BS4-MAX-7.2KW | BS4-MAX-8.2KW | BS4-MAX-10.2KW | BS4-MAX-10.8KW |
Phase | 1-phase | |||
Maximum PV Input Power | 7200W | 8200W | 10200W | 10800W |
Rated Output Power | 7200W/7200VA | 8200W/8200VA | 10200W/10200VA | |
Maximum Solar Charging Current | 140A | 160A | 160A | 160A |
GRID-TIE OPERATION | ||||
PV Input(DC) | ||||
Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | |||
Start-up Voltage/lnitial Feeding Voltage | 90VDC/120VDC | |||
MPPT Voltage Range | 90VDC-450VDC | |||
Number of MPPT Trackers/Maximum Input Current | 1/27A | 2/18A | ||
GRID OUTPUT(AC) | ||||
Nominal Output Voltage | 220/230/240VAC | |||
Output Voltage Range | 195-253VAC | |||
Nominal Output Current | 31.3A | 35.6A | 44.3A | |
Power Factor | >0.99 | |||
Feed-in Grid Frequency Range | 49~51±1Hz | |||
EFFICIENCY | ||||
Maximum Conversion Efficiency(DC/AC) | 98% | |||
TWO LOAD OUTPUT POWER | ||||
Full Load | 7200W | 8200W | 10200W | |
Maximum Main Load | 7200W | 8200W | 10200W | |
Maximum Second Load(battery mode) | 2400W | 2733W | 3400W | |
Main Load Cut Off Voltage | 44VDC | 44VDC | 44VDC | |
Main Load Return Voltage | 52VDC | 52VDC | 52VDC | |
OFF-GRID OPERATION | ||||
AC INPUT | ||||
AC Start-up Voltage/Auto Restart Voltage | 120-140VAC/180VAC | |||
Acceptable Input Voltage Range | 90-280 VAC or 170-280VAC | |||
Maximum AC Input Current | 40A | 40A | 50A | |
Nominal operating frequency | 50/60Hz | |||
Surge power | 14400W | 16400W | 20400W | |
PV INPUT(DC) | ||||
Maximum DC Voltage | 500VDC | |||
MPPT Voltage Range | 90VDC-450VDC | |||
Number of MPPT Trackers/Maximum Input Current | 1/27A | |||
BATTERY MODE OUTPUT(AC) | ||||
Nominal Output Voltage | 220/230/240VAC | |||
Output Waveform | Pure sine wave | |||
Efficiency(DC to AC) | 94% | |||
BATTERY&CHARGER | ||||
Nominal DC Voltage | 48VDC | 48VDC | 48VDC | |
Maximum Solar Charging Current | 140A | 160A | 160A | |
Maximum AC Charging Current | 120A | 140A | 140A | |
GENERAL | ||||
PHYSICAL | ||||
Dimension,D X W X H(mm) | 420*310*110 | 530*420*160 | ||
Cartoon Dimension,D X W XH(mm) | 588*463*205 | 618*463*205 | ||
Net Weight(kgs) | 13.1 | 14.2 | 14.5 | 14.8 |
Gross Weight(kgs) | 14.1 | 15.7 | 16 | 16.3 |
INTERFACE | ||||
Communication Port | RS232/WIFI//GPRS/Lithium Battery | |||
ENVIRONMENT | ||||
Operating Temperature | -10-50℃ | |||
