600W MPPT On Grid Tie Solar Microinverter
600w 700w 800w Microinverter> IP65 waterproof grade
> Back outlet hole to prevent electric shock
> Smartphone APP intelligence system
> Better heat dissipation
> 20% More Efficient Than Traditional Solar Inverter
> MPPT power automatic tracking
> CE, FC, PSE, UL, CE, RoHS, ISO9001 certificated
MPPT grid-connected solar micro inverter has powerful performance and excellent protection function. The 600 watts of power make it ideal for small solar systems. With WIFI function and IP65 waterproof design, it is more intelligent and durable. 300-2000 watts of power and 120 volts/230 volts can be selected according to demand. The product is exported to Europe, America, the Middle East and Africa, showing excellent market adaptability and reliability. No matter where you are, this grid-connected solar micro inverter can provide you with efficient solar conversion and help you achieve sustainable development goals.
- High efficiency: MPPT engine is used to achieve the maximum efficiency of energy conversion
- Intelligent: Equipped with intelligent wifi module, which can realize remote monitoring and control
- Multiple security protections: with multiple security protection functions to ensure safety during use
- Simple installation: easy and convenient installation, suitable for various scenarios
- Excellent reliability: After rigorous testing and verification, it has good performance and reliability
Specification
Model | 600W | 700W | 800W | |
Input(DC) | Recommend solar panel input power (W) | 200-300W*2 | 250-350W*2 | 275-400W*2 |
Number of DC input connections (groups) | MC4*2 | |||
Maximum DC input voltage | 52Vdc | |||
Operating voltage range | 20Vdc-50Vdc | |||
Start-up voltage | 18Vdc | |||
MPPT Tracking Range | 22Vdc-48Vdc | |||
MPPT Tracking accuracy | >99.5% | |||
Maximum DC input current | 14A*2 | |||
Output(AC) | Rated output power | 550W | 650W | 750W |
Maximum output power | 600W | 700W | 800W | |
Rated output voltage | 120Vac 230Vac | |||
Output voltage range | 90Vac-160Vac 190Vac-270Vac | |||
Rated AC current (at 120V) | 5A | 5.83A | 6.6A | |
Rated AC Current (at 230V) | 2.6A | 3A | 3.47A | |
Rated output frequency | 50HZ 60HZ | |||
Output frequency range (HZ) | 47.5Hz-50.5Hz 58.9Hz-61.9Hz | |||
THD | <5% | |||
Power factor | >0.99 | |||
Maximum number of branch circult connections | @120Vac : 5 set /@230Vac : 10 set | |||
Efficiency | Maximum conversion efficiency | 95% | 94.5% | 94% |
CEC efficiency | 92% | |||
Night losses | <80 mW | |||
Protetion function | Over / under voltage protection | Yes | ||
Over / under frequency protection | Yes | |||
Anti-islanding protection | Yes | |||
Over current protection | Yes | |||
Over load protection | Yes | |||
Over temperature protection | Yes | |||
protection class | IP 65 | |||
Working environment temperature | -40~65℃ | |||
Weight (Kg) | 2.5Kg | |||
Indication lights quantity | working status LED light *1 + Wifi signal LED light*1 | |||
Communication connection mode | Wifi/2.4G | |||
Cooling method | Natural cooling (no fan) | |||
Working environment | Indoor and outdoor | |||
Certification standards | EN1000-3-2 EN61000-3-3 EN62109-2 EN55032 EN55035 EN50438 | |||
